FRAMESET
FORK
RockShox 35 Silver R 130mm travel. Coil, 44mm offset, 15x110 QR axle, 1.5" tapered steerer tube
FRAME
6061 Single-Butted Aluminum Alloy
FRAME STYLE
Step-Over
WHEELSET
HUBS
15x110 32H Front, 12x148 32H Rear
RIM
Double Wall Aluminum 32h Front & Rear
SPOKES
Black Stainless 13 Gauge
TIRES
S Maxxis Rekon 27.5x2.4", M/L/XL Maxxis Rekon 29x2.4"
TUBES
Butyl Rubber, Presta Valve
EBIKE SYSTEM
BATTERY
Aventon 708 WH. 36V LG 21700 cells.
CHARGER
42V 4A charger
DISPLAY
LCD Smart "Easy Read"
MOTOR
Aventon a100 mid-drive. 36v, 250W (sustained), 750W (peak), 100NM torque. IP67 rating
BRAKES
REAR BRAKE ROTOR
Sram 180mm 6 bolt
FRONT BRAKE ROTOR
Sram 200mm 6 bolt
BRAKES
Sram DB8 mineral 4 piston hydraulic disc brakes
DRIVETRAIN
REAR DERAILLEUR
Sram NX Eagle 1x12
PEDALS
9/16" Alloy Platform
CHAINRING
Sram Nx 34t
CASSETTE
Sram SX Eagle 1x12 11-50t
SHIFT LEVER
Sram NX Eagle 1x12 single click
COCKPIT
SEATPOST
150mm travel for size M-XL. 125mm travel for size S. 31.6mm ø. 395mm length
HANDLEBARS
35mm, 9° rise, 720mm width for size S, 760mm width for size M-XL
